15 KW Hybrid Solar Plan

Home
15 KW Hybrid Solar Plan

Here are the 15 KW 3 Phase Hybrid Solar Plan details of all products included in the package.

It Is a smart and reliable energy system designed to reduce electricity costs while providing dependable backup power.

Featuring high-quality solar panels, a hybrid inverter, and lithium battery storage, it delivers efficient performance for homes and commercial spaces.

Hybrid Inverter IP 65/66
Lithium Battery
A Grade Solar Panels

Solar Structure
Electrical & Mechanical Work
Civil Work & GM Cables + Tomzon Breaker

☀️ 15 KW 3-Phase Hybrid Solar System

☀️ 15 KW 3-Phase Hybrid Solar System
⚡ System Configuration
🔧 Component 📋 Specification
☀️ Solar Panels 23 × 650W = 14.95 KW
⚡ Hybrid Solar Inverter 15 KW • 3-Phase
🔋 Lithium Battery 48V • 314Ah = 15.07 KWh nominal

🔧 Component	📋 Specification
☀️ Solar Panels	23 × 650W = 14.95 KW
⚡ Hybrid Solar Inverter	15 KW • 3-Phase
🔋 Lithium Battery	48V • 314Ah = 15.07 KWh nominal

🏠 What Can You Run With This Solar System?

🏠 Appliance	⚡ Approx. Wattage	✅ Practical Quantity
🌀 Ceiling Fan	60–80W	✅ 15–20 Fans
💡 LED Light	15–20W	✅ 30–40 Lights
❄️ Refrigerator	150–250W	✅ 4–5 Refrigerators
❄️ 1 Ton Inverter AC	800–1,200W*	✅ 5 ACs
❄️ 1.5 Ton Inverter AC	1,200–1,600W*	✅ 3–4 ACs
❄️ 2 Ton Inverter AC	1,600–2,200W*	✅ 3 ACs
💧 Submersible Pump	1,000W	✅ 2 Pumps
💧 Water Pump	2,000W	✅ 2 Pumps
🧺 Washing Machine	500–1,000W	✅ 2 Machines
📺 LED TV	80–150W	✅ 3–4 TVs
🔥 Electric Iron	1,000–2,000W	✅ 2 Irons

*Actual AC consumption varies according to model, temperature, compressor speed and operating conditions.

🔢 Want to Know What Load This Solar System Can Handle?

A practical daytime combination could be:

❄️ 4 × 1 Ton Inverter AC → ≈ 4,000W
🌀 15 × Ceiling Fans → ≈ 1,050W
💡 20 × LED Lights → ≈ 400W
❄️ 4 × Refrigerators → ≈ 800W
📺 2 × LED TVs → ≈ 200W
💧 1 × 2,000W Water Pump → ≈ 2,000W

⚡ Estimated Running Load

4,000 + 1,050 + 400 + 800 + 200 + 2,000 = 8,450W

➡️ Estimated load ≈ 8.45 KW

This remains comfortably within the 15 KW 3-Phase inverter capacity, leaving approximately 6.55 KW of additional capacity under these assumptions.

🔋 How Long Can a 16 KWh Lithium Battery Power Your Home?

Your 48V × 314Ah battery provides approximately 15.1 KWh of nominal energy storage, commonly marketed as a 16 KWh lithium battery.

For example, at an average 5 KW load:

15.1 KWh ÷ 5 KW ≈ 3 hours

Actual backup time depends on usable battery capacity, inverter efficiency, battery reserve settings and actual appliance consumption.

⚠️ Important Note !

The quantities above are practical load-planning estimates, not a guarantee that every appliance can operate simultaneously at maximum rated power.

ACs, refrigerators and pumps may require higher starting/surge power. The actual combined load should remain within the 15 KW 3-Phase Hybrid Inverter’s rated and surge capacity.

🌞 Powerful 3-Phase Solar Solution

14.95 KW Solar Panels + 15 KW 3-Phase Hybrid Inverter + 15.1 KWh Lithium Battery

✅ High Solar Generation
✅ Powerful 3-Phase Power Management
✅ Reliable Battery Backup
✅ Reduced Grid Dependence
✅ Suitable for Large Homes & Commercial Loads

Hybrid Inverters

⚡ 15 kW 3-Phase Hybrid Inverter

GoodWe | IP66 | Company Warranty Included

🔌 GoodWe 15 kW 3-Phase Hybrid Inverter

⚡ Inverter Benefits
Premium GoodWe hybrid inverter designed for efficient solar energy conversion, battery integration, backup power, and intelligent energy management.

🛡️ Company Warranty Included
Company warranty included for greater customer confidence, dependable after-sales support, and long-term peace of mind.

💧 IP66 Protection
IP66-rated protection provides a high level of resistance against dust and powerful water jets, supporting reliable operation in demanding installation environments.

🔄 3-Phase Power Management
Designed for efficient management of 3-phase electrical loads, making it suitable for residential, commercial, and high-demand solar applications.

🚀 High Performance
Engineered for stable and efficient power conversion with reliable management of solar, battery, grid, and connected loads.

☀️ Smart Energy Management
Intelligently manages available solar generation and energy storage to maximize solar utilization and provide dependable backup power.

🔋 16 KW Lithium Battery Bank

🔋 16 kW Lithium Battery Power Bank

48V | 314Ah • Reliable Energy Storage • Company Warranty Included

🔋 16 kW Lithium Battery

ITEL | Apex | Soluna

⚡ Battery Benefits
High-capacity lithium battery options designed for efficient solar energy storage, reliable backup power, and advanced daily energy management.

🛡️ Company Warranty Included
Company warranty included for greater customer confidence, dependable after-sales support, and peace of mind.

🔋 48V | 314Ah Capacity
Provides approximately 15.1 kWh nominal energy storage, making it suitable for high-capacity hybrid solar systems and extended backup requirements.

🚀 Performance
Designed for efficient charging and discharging, stable power delivery, and reliable long-term energy storage.

🔄 High-Capacity Power Bank
Stores more solar energy to support longer backup operation and maximize the utilization of available solar power.

A Grade Solar Panels

☀️ LONGi Hi-MO X10 Solar Panels

🏆 Tier-1 | 600W–650W | Advanced Solar Technology

⚡ High Power Output
High-wattage modules designed to deliver strong solar generation while making efficient use of available roof space.

🔬 Advanced HPBC 2.0 Technology
LONGi Hi-MO X10 uses advanced HPBC 2.0 cell technology, developed to deliver higher power generation and improved module performance.

🏆 Tier-1 Quality
Premium LONGi modules selected for reliable performance, long-term energy generation, and professional solar installations.

☀️ High Module Efficiency
Hi-MO X10 technology offers high conversion efficiency, with official X10 models reaching up to 24.8% efficiency.

🌡️ High-Temperature Performance
Designed to maintain strong performance under demanding outdoor conditions, with a Pmax temperature coefficient of approximately -0.260%/°C on the cited X10 640–665W series.

💪 Strong & Durable Construction
Selected X10 models are tested for high mechanical loads, including up to 5400 Pa front-side loading and 2400 Pa rear-side loading.

🌧️ Weather-Resistant Design
Built for outdoor solar applications with durable construction and weather-resistant components. Specific X10 models feature IP68-rated junction boxes.

🌑 Better Shading Performance
Hi-MO X10 incorporates shading optimization designed to help minimize power losses caused by partial shading.

🛡️ Enhanced Reliability
LONGi highlights improved resistance to degradation mechanisms and enhanced system-level reliability for long-term solar applications.

📈 Long-Term Energy Generation
Built to provide dependable solar power generation over the system’s operating life, helping maximize energy savings and return on your solar investment.

🔧 Professional Solar Solution
Ideal for residential, commercial, and industrial solar installations, offering a combination of high power, efficiency, durability, and modern solar technology.

Pre-Manufactured GI Solar Structure

🏗️ Pre-Manufactured GI Solar Structure

L1 | L2 | L3 | L4 — 14-Gauge GI Structure

💪 Heavy-Duty Construction
Pre-manufactured 14-gauge GI structure designed to provide strong, stable, and reliable support for solar panels.

🛡️ 14-Gauge Galvanized Iron
High-quality GI material provides excellent durability and enhanced resistance against rust and outdoor environmental conditions.

🔩 L1 | L2 | L3 | L4 Options
Multiple structural configurations available to accommodate different installation requirements, roof designs, and panel layouts.

⚙️ Precision Pre-Manufacturing
Pre-manufactured components help provide accurate fitting, faster installation, and a clean professional finish.

☀️ Optimized Panel Support
Designed to securely hold solar panels while maintaining proper positioning for efficient solar generation.

🌧️ Weather-Ready Design
Built to withstand regular outdoor exposure and provide dependable long-term structural support.

Uplift / High-Beam Welded Structure

🏗️ Uplift / High-Beam Welded Structure

Heavy-Duty Welding | High Strength | Long-Term Support

💪 Heavy-Duty High-Beam Design
A robust welded structure designed for installations requiring additional strength, height, and stability.

🔥 Professional Welding
Strong welded joints provide a secure and rigid framework for supporting solar panels.

🏗️ High-Beam Construction
The elevated high-beam design provides increased structural strength and is suitable for demanding solar installations.

🛡️ Durable GI Construction
Built using quality structural material to provide reliable outdoor performance and resistance against environmental conditions.

⚡ Strong & Stable Support
Designed to securely support solar panels and maintain structural stability during long-term operation.

🔧 Ideal for Large Installations
A suitable option for commercial, industrial, and large-scale solar projects where heavy-duty structural strength is required.

⚡ Complete Electrical Work

🔌 Premium Electrical Components & Professional Installation

🏠 Indoor / Outdoor DB Boxes
High-quality distribution boxes for organized, secure, and professional electrical connections.

🔌 Pure Copper AC/DC Cables — 4mm to 10mm
High-quality pure copper cables available in 4mm, 6mm, and 10mm sizes, selected according to system requirements for reliable and efficient power transmission.

🛠️ Cable Trays & Flexible Pipes
Professional cable management solutions to keep wiring organized, protected, and safely routed.

⚡ AC/DC Breakers
Quality protection devices designed to help safeguard the solar system and electrical circuits from overloads and faults.

🛡️ Outdoor Breakers
Durable protection components designed for reliable outdoor solar installations.

🔥 Fire Breaker / Safety Protection
Additional electrical safety protection to enhance overall system security.

🏆 Trusted Electrical Brands
All major cables and breakers are sourced from trusted brands, including:

GM Cables | Pakistan Cables | Prime Cables | Tomzon | CHINT

🔧 Professional Electrical Installation
All electrical components are carefully selected and professionally installed to provide a safe, reliable, organized, and long-lasting solar electrical system.

🏗️ Mechanical Work

Strong, Reliable & Professionally Installed Solar Structures

🔩 Pre-Manufactured Solar Structure — L1 | L2 | L3 | L4
Pre-manufactured solar structures designed for accurate fitting, quick installation, strong panel support, and a clean professional finish. Available in L1, L2, L3, and L4 configurations according to installation requirements.

🏗️ High-Beam Welding Structure
Heavy-duty high-beam welded structure designed for enhanced strength, stability, and long-term solar panel support. Ideal for demanding residential, commercial, and industrial installations.

🔩 SS Nuts & Bolts
High-quality stainless-steel nuts and bolts for secure and durable structural connections.

⚙️ Heavy-Duty Rawl Bolts
Heavy-duty Rawl Bolts used for strong and secure anchoring of the solar structure to the foundation.

🔧 High-Tension Glue & Washers
High-tension fastening components with quality washers to provide firm, secure, and reliable structural connections.

🧱 Supports & Foundation Plates
Strong support components and foundation plates designed to provide stability, proper load distribution, and secure structural mounting.

💪 Professional Mechanical Installation
All structural components are professionally assembled and installed to provide a strong, stable, and long-lasting foundation for your solar system.

🧱 Civil Work

Professional Foundation & Finishing Work for Solar Structures

🏗️ Foundation Work
Professional civil foundation work for secure, stable, and long-lasting solar structure installation.

🎨 Oil Paint Finish
Quality oil paint applied to welded structure areas for a clean, professional, and durable finish.

⚪ White Color / 🔴 Red Color Options
Oil paint available in White and Red colors according to customer preference and project requirements.

🛡️ Red Oxide Protection
Red Oxide Primer applied to welded and exposed metal surfaces to help protect against rust and corrosion.

✨ Professional Finishing
Proper surface preparation, red oxide coating, and final oil paint provide the structure with a neat appearance and added protection against outdoor conditions.
